Custom Lid-and-Base Storage Boxes
A separate shallow lid fits over a deeper box body with hand openings. Plan the lid fit, lifting access and printed faces as one set.
- Style reference
- E60005
- Structure
- Separate lid · deep body · hand openings
- Dimensions
- Custom size, confirmed for your product
- Material
- Kraft appearance shown; board construction and grade to confirm
Size around your product.
Specify the body's usable internal space and identify the separate lid overlap.
- L
- LengthThe horizontal span across the assembled front face.
- W
- WidthThe front-to-back depth of the assembled box.
- H
- HeightThe vertical distance from the base to the closed top.
Lid size includes clearance over the body. Hand openings and the lid overlap reduce the uninterrupted printed area.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
The small separate dieline is the lid. The longer four-panel section forms the body, with openings on two opposing sides and flaps below.
Make the lid the main display surface.
Centre the primary brand element on the lid top and allow the shallow walls to fold down around it.
- Check the logo orientation relative to the hand openings.
- Keep essential detail away from lid corner joints.
Design below the lid overlap.
Place supporting text where the lid will not cover it. Repeat a short label on more than one side if useful.
- Measure the visible body area with the lid fitted.
- Keep key content away from the vertical seam.
Leave clear space around the cut-outs.
Treat the two hand openings as interruptions in the artwork, not as solid printing surfaces.
- Avoid placing barcodes across the openings.
- Check any background pattern around the cut edges.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60005.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
The sizes below refer to the body cavity; the lid and hand openings need a separate fit and layout check.
| Product & example size | Suggested body internal dimensions | Material to consider | Selection & fit notes |
|---|---|---|---|
| A folded scarf gift setExample packed product: 220 × 180 × 70 mm |
245 × 205 × 95mm · L × W × H | Kraft-faced corrugated board | Allow for tissue and check the depth below the lid. |
| Small boxed retail itemsExample packed product: 250 × 220 × 120 mm |
275 × 245 × 150mm · L × W × H | White-faced corrugated board | Plan the item arrangement and hand-opening position together. |
| A stationery presentation setExample packed product: 285 × 230 × 80 mm |
310 × 255 × 110mm · L × W × H | Kraft-faced corrugated board | A starting footprint for stacked stationery with wrapping. |
| A fabric accessory bundleExample packed product: 300 × 250 × 150 mm |
330 × 280 × 180mm · L × W × H | Kraft-faced corrugated board | Check the real folded bundle and the finished pack weight. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample. Hand openings do not establish a load rating; confirm the complete box construction for the intended contents.
