Style reference. Size, materials and printing are customized for your order.
Custom Document Boxes
Plan the front, side walls and opening around the full document set, including covers and projecting tabs.
- Style reference
- E61382
- Structure
- Open-top document box
- Dimensions
- Custom size, confirmed for your product
- Material
- Paperboard substrate, thickness and finish to confirm
Size around your product.
Supply the full loaded stack and confirm access through the opening.
- L
- LengthFirst horizontal span of the assembled document cavity or outside base; state the chosen basis.
- W
- DepthFront-to-back span in the same internal or outside basis.
- H
- HeightAssembled vertical height; identify high and low edges separately for a slanted holder.
Supply the full loaded stack and confirm access through the opening.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
Place the identifying information on the face visible in its storage position.
Visible front.
Place the identifying information on the face visible in its storage position.
Storage orientation.
Place identifying information on the face visible when the full file set is stored.
- Place the identifying information on the face visible in its storage position.
Opening & closure.
Supply the full loaded stack and confirm access through the opening.
- Place the identifying information on the face visible in its storage position.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E61382.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
Choose a starting format for this product type, then confirm it against your content, use and selected construction.
| Product & example size | Assembled document cavity or outside envelope; state the basis | Material to consider | Selection & fit notes |
|---|---|---|---|
| A small document setComplete file set: Complete cards or small documents, including covers |
Develop from the full file stackConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Check the usable base, stack thickness and access opening together. |
| An A5 file setComplete file set: 148 × 210 sheets plus sleeves and projecting tabs |
Develop from the full loaded arrangementConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | The assembled box depth is separate from a single sheet trim. |
| An A4 file setComplete file set: 210 × 297 sheets plus folders and covers |
Develop from the full loaded arrangementConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Check the closure and removal access around the complete set. |
| A slanted upright file holderComplete file set: Actual documents in their storage orientation |
Confirm base and high/low side heightsConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Give the sloping opening profile in addition to the maximum outside envelope. |
These are illustrative design starting points, not stock sizes or measurements of this reference. Confirm material, construction, printing and sample fit before production. Use one internal or outside basis consistently; the full file stack determines fit, not a single sheet.
