Style reference. Size, materials and printing are customized for your order.
Custom Four-Compartment Trays
A tray holds a divided product arrangement. Plan the outer walls and the separate internal dividers as different components. Confirm the cell count, individual opening and full packed arrangement.
- Style reference
- E60749
- Structure
- Tray with separate dividers · multi-cell arrangement
- Dimensions
- Custom size, confirmed for your product
- Material
- SBS or kraft paperboard; grade and caliper to confirm
Size around your product.
Specify the full tray cavity, individual cell dimensions and divider height; confirm the complete product arrangement.
- L
- LengthThe longer side across the usable base.
- W
- WidthThe shorter side across the usable base.
- H
- HeightThe usable depth from the base to the closed top, or the open rim where applicable.
For a tapered tray, provide both base and rim dimensions. State whether depth is measured to the lowest rim, and identify any separate lid or cover.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
Use visible tray walls for the main design and keep divider artwork separate from the outside presentation.
Visible tray walls.
Use visible tray walls for the main design and keep divider artwork separate from the outside presentation.
Dividers.
Plan each divider as a separate piece and print only where its surface remains visible after loading.
- Confirm the cell count, individual opening and full packed arrangement.
Corner folds.
Specify the full tray cavity, individual cell dimensions and divider height; confirm the complete product arrangement.
- Use visible tray walls for the main design and keep divider artwork separate from the outside presentation.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60749.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
Choose a starting format for this product type, then confirm it against your content, use and selected construction.
| Product & example size | Suggested tray internal envelope; individual cells separately confirmed | Material to consider | Selection & fit notes |
|---|---|---|---|
| Four small wrapped piecesExample project: Each item about 40 × 40 × 25 |
100 × 100 × 35mm · L × W × H | SBS or kraft paperboard; grade and caliper to confirm | Plan four cells and include divider thickness between the pieces. |
| Four compact retail itemsExample project: Each item about 55 × 45 × 30 |
130 × 110 × 45mm · L × W × H | SBS or kraft paperboard; grade and caliper to confirm | Check the 2-by-2 arrangement and the individual cell clearances. |
| Four small jars in a trayExample project: Each wrapped item about 45 × 45 × 45 |
110 × 110 × 60mm · L × W × H | SBS or kraft paperboard; grade and caliper to confirm | Confirm the complete tray fit and whether the dividers support the chosen items. |
| A mixed four-piece setExample project: The four actual outlines in their planned order |
Develop separate cell widths around the arrangementConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | The overall tray dimensions alone do not establish the size of each cell. |
These are illustrative design starting points, not stock sizes or measurements of this reference. Confirm material, construction, printing and sample fit before production.
