Custom Interlocking Corner Trays
An open rectangular tray with folded walls and interlocking corner tabs. Plan the base footprint and visible wall artwork around the contents.
- Style reference
- E60009
- Structure
- Open top · shallow walls · interlocking corners
- Dimensions
- Custom size, confirmed for your product
- Material
- Kraft paperboard appearance shown; board grade and thickness to confirm
Size around your product.
Use the contents' footprint to set the base size, then select a useful wall height.
- L
- LengthThe longer side of the usable tray base.
- W
- WidthThe front-to-back span across the usable tray base.
- H
- Wall heightThe vertical depth from the base to the top edge of the tray walls.
The corners fold into the tray. Check the usable corner space and specify any lid or outer sleeve separately.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
The central rectangle is the base. The four surrounding strips become walls, with small corner tabs that fold and interlock.
Decide how much artwork stays visible.
Place interior graphics around the planned contents or use the base for a consistent background.
- Check the loaded tray as well as the empty tray.
- Specify inside printing separately.
Put short information on the outside faces.
A short logo or product line can work on the shallow outer walls when enough space remains after folding.
- Keep small text away from the top cut edge.
- Align patterns at wall folds.
Keep the locking tabs functional.
Corner tabs overlap after assembly. Keep essential images and text on the uninterrupted wall areas.
- Mark concealed tab areas in the artwork.
- Check the corner locks on the chosen board.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60009.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
These examples use already wrapped contents; a separate lid or shipping pack can be developed around the tray.
| Product & example size | Suggested tray internal dimensions | Material to consider | Selection & fit notes |
|---|---|---|---|
| Two wrapped soap barsExample packed product: 160 × 65 × 25 mm |
180 × 85 × 35mm · L × W × H | Kraft paperboard | A shallow tray with clearance around the wrapped pair. |
| A small stationery bundleExample packed product: 190 × 130 × 25 mm |
210 × 150 × 40mm · L × W × H | SBS white paperboard | A white surface for presentation graphics. |
| A folded fabric accessoryExample packed product: 230 × 170 × 35 mm |
255 × 195 × 50mm · L × W × H | Kraft paperboard | Allow for tissue and folded corners. |
| A set of small boxed goodsExample packed product: 260 × 180 × 40 mm |
285 × 205 × 55mm · L × W × H | Kraft-faced corrugated board | Discuss the load and review the corner design for the chosen board. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample.
