Custom Open-Top Document Boxes with Locking Bases
Plan the open-top enclosure around the complete document stack and its insertion direction.
- Style reference
- E60232
- Structure
- Open-top document box
- Dimensions
- Custom size, confirmed for your product
- Material
- SBS or kraft paperboard; grade and caliper to confirm
Size around your product.
Specify usable internal width, stack depth and height; review the base and removal access.
- L
- LengthFirst horizontal span of the assembled document cavity or outside base; state the chosen basis.
- W
- DepthFront-to-back span in the same internal or outside basis.
- H
- HeightAssembled vertical height; identify high and low edges separately for a slanted holder.
Supply the full loaded stack and confirm access through the opening.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
Orient the front and back information below the open rim and clear of thumb notches.
Visible front.
Orient the front and back information below the open rim and clear of thumb notches.
Storage orientation.
Place identifying information on the face visible when the full file set is stored.
- Orient the front and back information below the open rim and clear of thumb notches.
Opening & closure.
Specify usable internal width, stack depth and height; review the base and removal access.
- Orient the front and back information below the open rim and clear of thumb notches.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60232.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
Measure the full document stack, sleeves and any projecting tabs. The reference is open at the top; a top tuck-closure allowance is not the sizing basis.
| Product & example size | Complete document stack and usable open-top enclosure | Material to consider | Selection & fit notes |
|---|---|---|---|
| Document stackInformation to provide: Finished sheet width and height, plus full stack thickness |
Develop usable width, depth and heightConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Include sleeves and tabs in the maximum outline. |
| Insertion accessInformation to provide: Preferred loading direction and access above the rim |
Confirm opening and thumb-notch positionConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Check removal with the complete stack loaded. |
| Assembled baseInformation to provide: Base folds and wall thickness |
Confirm usable internal depth separatelyConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | The base construction reduces the usable space. |
| Printed facesInformation to provide: Main reading face and visible back |
Confirm artwork relative to the open rimConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Keep small text clear of folded rim and notch areas. |
This is a project-specific sizing brief, not a stock size or a measurement inferred from the reference image. Confirm the selected structure, substrate, clearances and assembled sample before production.
Discuss your size & material
