Custom Pillow Boxes
Two curved main faces and folding end flaps form a pillow-shaped pack. Keep the product within the curved cavity and place the main artwork away from the ends.
- Style reference
- E60011
- Structure
- Two curved faces · curved end folds · side seam
- Dimensions
- Custom size, confirmed for your product
- Material
- White paperboard appearance shown; board grade and crease specification to confirm
Size around your product.
Share both the product dimensions and the proposed overall pillow-box envelope. The internal cavity narrows near the ends.
- L
- LengthThe overall end-to-end length of the assembled pillow box.
- W
- WidthThe overall span across the broad curved face.
- H
- DepthThe maximum assembled thickness at the centre; the ends are shallower.
Overall dimensions do not describe a rectangular usable cavity. Test the product against the curved ends and closure.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
The dieline has two broad panels, four curved end flaps and one long seam tab. The curved fold lines define the usable artwork area.
Keep the main design in the central area.
Place the logo or product name where the curved face is widest and least affected by the end folds.
- Avoid placing key text across curved creases.
- Review distortion on the assembled shape.
Reserve the reverse for supporting detail.
Place a short description or small label on the opposite face while leaving the seam area clear.
- Confirm the side seam position.
- Keep background patterns simple around the seam.
Let the curved ends close freely.
Use the end flaps for background colour instead of dense text; the folds and thumb notches interrupt the surface.
- Keep important detail away from the notches.
- Check both ends with the product inside.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60011.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
These sizes describe the overall pillow shape, not a rectangular internal capacity. Fit must be checked at the curved ends.
| Product & example size | Suggested assembled external envelope | Material to consider | Selection & fit notes |
|---|---|---|---|
| A small gift card and sleeveExample packed product: 90 × 60 × 5 mm |
130 × 90 × 20mm · L × W × H | SBS white paperboard | Keep the card clear of the inward-folded curved ends. |
| A jewellery pouchExample packed product: 70 × 55 × 15 mm |
120 × 85 × 30mm · L × W × H | Kraft paperboard | Use the soft pouch shape to check the curved cavity. |
| A light fabric accessoryExample packed product: 120 × 75 × 20 mm |
170 × 115 × 35mm · L × W × H | SBS white paperboard | Allow room around the folded accessory without forcing the ends. |
| A small scarf folded flatExample packed product: 160 × 100 × 20 mm |
210 × 140 × 40mm · L × W × H | Kraft paperboard | Recheck the actual fold, tissue and finished closure. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample.
