Custom Reverse Tuck-End Cartons
A four-panel folding carton with top and bottom tuck flaps on opposite faces. Plan a clear front panel, the closure direction and the space around your product.
- Style reference
- E60003
- Structure
- Four body panels · opposing tuck ends
- Dimensions
- Custom size, confirmed for your product
- Material
- White paperboard appearance shown; grade and thickness to confirm
Size around your product.
Measure the wrapped product and allow room for the tuck flaps at both ends.
- L
- LengthThe horizontal span across the assembled front face.
- W
- WidthThe front-to-back depth of the assembled box.
- H
- HeightThe vertical distance from the base to the closed top.
Include caps, sleeves and any insert. The flat artwork dimensions are not the same as the carton dimensions.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
The dieline has four connected body panels and a narrow side seam. The main top and bottom flaps attach to opposite body panels.
Choose one main display face.
Place the product name and primary image on the selected front; use the opposite face for supporting information.
- Check the front orientation with the top flap closed.
- Keep text within the panel safe area.
Use the narrow faces for supporting detail.
Arrange a short description, variant information or a repeating background on the side panels.
- Keep the side seam clear of important text.
- Check alignment across each vertical fold.
Plan both closure directions.
The top and bottom tuck flaps fold from opposite faces. Treat their artwork orientation separately.
- Keep barcodes off tuck tips and dust flaps.
- Check the reading direction on an assembled sample.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60003.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
Use these wrapped-product examples to discuss a carton size and a print surface.
| Product & example size | Suggested carton internal dimensions | Material to consider | Selection & fit notes |
|---|---|---|---|
| A wrapped soap barExample packed product: 80 × 55 × 25 mm |
90 × 65 × 35mm · L × W × H | SBS white paperboard | Room around the wrap; use the broad face for the soap name. |
| A small cosmetic jarExample packed product: 55 × 55 × 45 mm |
65 × 65 × 55mm · L × W × H | SBS white paperboard | Measure the lid as well as the body and discuss a separate insert if needed. |
| A boxed fashion accessoryExample packed product: 70 × 70 × 35 mm |
80 × 80 × 45mm · L × W × H | Kraft paperboard | A kraft starting point with clearance for the inner sleeve. |
| A compact stationery setExample packed product: 90 × 60 × 40 mm |
105 × 75 × 55mm · L × W × H | SBS white paperboard | Check the complete stack and both tuck closures. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample.
