Custom Shipping Cartons
A four-panel shipping carton with top and bottom flaps. Plan the packing arrangement, closing method and printed shipping information together.
- Style reference
- E60012
- Structure
- Four body panels · top and bottom flaps · side seam
- Dimensions
- Custom size, confirmed for your product
- Material
- Kraft board appearance shown; corrugated board grade and flute to confirm
Size around your product.
Measure the complete packed arrangement, including the protection and any inner cartons.
- L
- LengthThe horizontal span across the assembled front face.
- W
- WidthThe front-to-back depth of the assembled box.
- H
- HeightThe vertical distance from the base to the closed top.
Choose the board and closing method for the actual load and distribution conditions. Outer dimensions will be larger than the usable cavity.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
Four connected body panels are bordered by top and bottom flaps. The narrow side tab forms the joining seam.
Use the main panels for identification.
Place the brand, item description or handling information on the broad body faces.
- Keep variable labels in a clear area.
- Avoid the manufacturer's joining seam.
Leave room for the shipping label.
Reserve a flat, uninterrupted area that works with the intended packing and fulfilment process.
- Keep the label clear of folds and tape paths.
- Confirm placement with the shipping workflow.
Plan artwork around the seal.
The top and bottom flaps fold and are sealed during packing. Tape or other closures can cover graphics.
- Avoid critical messages beneath the sealing strip.
- Check orientation with the box closed.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60012.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
The product envelope below already includes the planned protection or inner boxes; allow additional assembly and loading clearance.
| Product & example size | Suggested shipping carton internal dimensions | Material to consider | Selection & fit notes |
|---|---|---|---|
| A protected small retail boxExample packed product: 180 × 140 × 100 mm |
200 × 160 × 120mm · L × W × H | Kraft-faced corrugated board | Check the inner pack and closure with the actual product weight. |
| A group of boxed accessoriesExample packed product: 260 × 220 × 150 mm |
285 × 245 × 175mm · L × W × H | Kraft-faced corrugated board | Confirm the arrangement and whether dividers are needed. |
| A wrapped apparel bundleExample packed product: 320 × 250 × 160 mm |
345 × 275 × 185mm · L × W × H | Kraft-faced corrugated board | Measure the real bundle without over-compressing the contents. |
| Several protected stationery setsExample packed product: 380 × 280 × 220 mm |
405 × 305 × 245mm · L × W × H | Kraft-faced corrugated board | Choose board grade and sealing method for the filled load. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample. No transit performance or stacking strength is established by these dimensions alone.
