Custom Two-Compartment Carry Trays
Two open compartments sit on either side of a raised central handle. Plan the outer wall artwork and the central panel around the complete loaded arrangement.
- Style reference
- E60422
- Structure
- Two-compartment tray with central handle
- Dimensions
- Custom size, confirmed for your product
- Material
- SBS or kraft paperboard; grade and caliper to confirm
Size around your product.
Specify each usable compartment, overall footprint and full height including the central handle; review the complete packed sample.
- L
- LengthThe longer side across the usable base.
- W
- WidthThe shorter side across the usable base.
- H
- HeightThe usable depth from the base to the closed top, or the open rim where applicable.
For a tapered tray, provide both base and rim dimensions. State whether depth is measured to the lowest rim, and identify any separate lid or cover.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
Keep the handle opening clear and check that both compartment-facing surfaces read correctly when loaded.
Choose the main viewing surface.
Keep the handle opening clear and check that both compartment-facing surfaces read correctly when loaded.
Arrange the secondary information.
Use other visible areas for supporting details without relying on a surface covered by the contents.
- Keep the handle opening clear and check that both compartment-facing surfaces read correctly when loaded.
Check the design against the approved layout.
Specify each usable compartment, overall footprint and full height including the central handle; review the complete packed sample.
- Keep the handle opening clear and check that both compartment-facing surfaces read correctly when loaded.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60422.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
Measure the complete two-part product arrangement. The raised central handle and partition are separate from the usable depths of the two compartments.
| Product & example size | Overall tray base, individual compartments and handle separately | Material to consider | Selection & fit notes |
|---|---|---|---|
| First compartmentInformation to provide: Full packed item outline and quantity |
Develop the first usable compartmentConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Confirm loading and removal access. |
| Second compartmentInformation to provide: Full packed item outline and quantity |
Develop the second usable compartmentConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Do not assume both compartments have identical capacities. |
| Whole trayInformation to provide: Overall assembled footprint and wall height |
Confirm the complete tray envelopeConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Include partition thickness in the layout. |
| Central handleInformation to provide: Handle projection, grip opening and loaded arrangement |
Specify full height including the handleConfirm for your product | SBS or kraft paperboard; grade and caliper to confirm | Review carrying on the actual assembled packed sample; no load rating is implied. |
This is a project-specific sizing brief, not a stock size or a measurement inferred from the reference image. Confirm the selected structure, substrate, clearances and assembled sample before production.
