Reference rendering of this structure. Artwork, material and final dimensions are confirmed for your project.
Custom Window Gable Boxes
A folding box with a gable top, integrated handle openings and a large front window. Plan the visible product and the printed frame together.
- Style reference
- E60008
- Structure
- Gable top · handle openings · front window
- Dimensions
- Custom size, confirmed for your product
- Material
- White paperboard appearance shown; window patch and board grade to confirm
Size around your product.
Measure the contents within the straight body section below the sloping roof.
- L
- LengthThe horizontal span across the front body panel.
- W
- WidthThe front-to-back depth between the body panels.
- H
- Body heightThe usable straight-wall height below the sloping roof; handle height is additional.
A handle-top dimension is not usable packing height. Specify the window and any clear patch separately.
Add your target size
Your values appear on the diagram and in your inquiry. The reference drawing stays at its original proportions.
Design for the finished product.
The four body panels sit below the handle and roof sections. The rectangular cut-out interrupts one broad body panel.
Let the contents and border work together.
Keep key wording in the solid frame around the window and place the product behind it deliberately.
- Do not place artwork over the cut-out.
- Confirm the window patch and attachment area.
Use the full back panel for detail.
Place product information on the uninterrupted rear face and use the side panels for a simple continuation.
- Check the reading direction after assembly.
- Allow for the side seam and bottom folds.
Respect the grip and closing tabs.
Use the roof areas for restrained background artwork while keeping small text away from the handle openings.
- Keep critical elements clear of slots and locking tabs.
- Review visibility with the top closed.
Prepare artwork on the approved production dieline at final size. Confirm bleed, print sides and safe margins before printing.
Request a production dielineTry your artwork on this reference
Select an area on the reference, add text or your logo, then adjust its direction and repeat pattern. Download a placement preview to include with your inquiry.
No target size added. Add your dimensions to include them in the preview.
Use the position fields as an alternative to dragging. Values are percentages of this reference image.
Loading the reference…
A placement concept, not a print-ready file. Confirm print sides, cutouts, glue areas and safe margins on your production layout. Your uploaded image stays in this browser.
- Keep the layers separate.
Place the dieline on its own reference layer. Keep it out of the printed artwork unless your production file instructions say otherwise.
- Check the reading direction.
Review logos and text in the finished orientation. Carry patterns across folds only after checking their alignment.
- Approve a physical reference.
Use the appropriate sample to check fit, opening and print position before confirming production.
Request a quote for this style.
Send your dimensions, quantity and artwork requirements for style E60008.
- Target size and measurement basis
- Quantity, product details and intended use
- Logo, artwork and finishing ideas
Need to check it in hand? Explore sample options ↗
Recommended sizes & materials for common products.
The table gives the rectangular packing space. The sloped roof and handle add to the overall external height.
| Product & example size | Suggested usable body internal dimensions, below the roof | Material to consider | Selection & fit notes |
|---|---|---|---|
| A small wrapped giftExample packed product: 100 × 65 × 80 mm |
120 × 85 × 100mm · L × W × H | SBS white paperboard | Place the gift where it is visible through the front window. |
| A compact accessory setExample packed product: 140 × 80 × 95 mm |
165 × 100 × 120mm · L × W × H | SBS white paperboard | Check the grouping and window position together. |
| A paper-wrapped stationery setExample packed product: 170 × 90 × 110 mm |
195 × 115 × 135mm · L × W × H | Kraft paperboard | A kraft starting point; confirm whether a window patch is required. |
| A folded lightweight scarfExample packed product: 180 × 110 × 100 mm |
205 × 135 × 125mm · L × W × H | SBS white paperboard | Allow for tissue and measure the contents below the roof folds. |
These are illustrative design starting points, not fixed stock sizes or confirmed production specifications. Example product dimensions include the planned wrapping. Confirm the complete pack, material grade and fit with a sample. The handle needs a load and assembly check for the intended contents.
